应用领域与简单介绍/Brief Introduction：

全电脑半自动型式注塞泵泵式膏体酱分安装系统都是我大公司转变市场上供给制作的新服务。这手机主要包括SUS304304不锈钢注塞泵泵式测量泵强制执行分装，且集电脑半自动式上盖、电脑半自动式旋盖、机械电力设备为集成，经济条件性价比高，拆迁赔偿范围小，大范围利用于药厂、饮食、农药杀菌剂、化工环保、定妆品等行业领域的介质液体标签印刷，具有GMP制约耍求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

的特点/characteristic：

◆用到注塞泵式检定泵履行分装，应用很多稠状度流体，精准度不高；泵的构造用到快接式取下公司，有助清晰、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式压力容器检验泵活塞式环板材随着服务业及介质因素的不一样的用硅塑胶，四氟氯乙烯或同一板材，特异情况用卫浴陶瓷板材。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC有效控制设计，直流变频变速，自行化系数高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装罐，自动的计算特点。Lack of bottle filling, automatic counting function◆装量修整简约，可是次修整基本的的计量泵的充填量，也可涉及其它的的计量泵实行微幅修整；工作简约，修整最快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头不设防渗漏设备，充填时前往瓶底包装，慢逐渐，以防止裂痕。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆组装机可支持有差异规格尺寸的塑料瓶子，整改简便方法，可在瞬日子内实现。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆一整台机器的按GMP要构思。The machine designed according to the requirements of GMP

技术水平参数设置/technic parameter：

不适用瓶盖年纪Size of bottles	20-1000ml（只能根据请求制作厂）20-1000 - ml (according to your need）
适合小瓶厚度Apply the bottle diameter	¢20-¢150mm
适宜盖子技术参数Apply the lid specifications	¢20-¢70mm
种植专业能力 production capacity	四头装灌：1000-2500瓶/时间 Four filling head: 1000-2500 bottles per hour 八头装罐：2500-4000瓶/小 Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/钟头 12 head filling: 4000-6000 bottles per hour
装量误差值The load error	±1%
旋盖合格证率Screw cover percent of pass	≥99%
开关电源power supply	380V，50HZ
热效率power	3.0KW
供气gas sources	0.4-0.75MPA
流速把握speed control	变频器调节variable speed
